Features & Specifications

1.Comply with ANSI/EIA, RS-310-D, IEC297-2, DIN41491; PART1, DIN41494; PART7, GB/T3047.2-92 standard, compatible with 19 inch international inner installation standard, metric system and ETSI standard.

2.The frame is designed as assembly structure,  the whole configuration is stable, static loading is more than 75Kgs.

3. Wall mounted design, quick installation and easy maintenance.

4. Side panels adopt quick open latches design, which makes the disassembly & assembly process conveniently.

5. Flat packing and assembled packing are available, providing good solution to save your transportation costs.

6. Axial flow fan unit is optional for active cooling. IP degree: IP 20.

7. The inner installation depth is adjustable (take 20MM as unit); the height of the capacity is adjustable (take 1U as unit).

8. International popular 5mm thickness of smoky gray colored toughened glass front door with small round lock, flat steel rear door with small round lock.

9. Customizations based on customer requirements are welcomed; various kinds of specifications and structure adjustment are available.

Surface treatment:

Degreasing, Pickling, Phosphating, Cleaning, Drying, Powder coating

Material:

High quality SPCC (cold rolled steel)

Thickness:

Mounting profile: 2.0mm, others: 1.2mm to 1.5mm

Surface color (optional):

RAL 9004 (Black) or RAL 7035(Grey)
